Pass Exam With Full Sureness - 300-425 Dumps with 113 Questions [Q43-Q59]

Rate this post

Pass Exam With Full Sureness – 300-425 Dumps with 113 Questions

Verified 300-425 dumps Q&As – 100% Pass from Real4exams

Finally, candidates must have a good understanding of security concepts and best practices when designing wireless networks. They must be able to implement security measures such as authentication, encryption, and access control to ensure the confidentiality, integrity, and availability of wireless network data. Overall, the Cisco 300-425 certification exam is an excellent opportunity for networking professionals to showcase their skills and advance their careers in the wireless networking field.

Certification Paths

In case you want to become a certified wireless engineer but you don’t know where to start, taking 300-425 exam is a good decision. First of all, it immediately brings one the Cisco Certified Specialist — Enterprise Wireless Design certification. Then, a candidate can earn the professional-level CCNP Enterprise certificate by passing the core test 350-401 ENCOR that focuses on implementing and operating Cisco Enterprise network core technologies. Other concentration exams one can choose to pass instead of 300-425 include 300-410, 300-415, 300-420, 300-430, 300-435.

Moreover, this is not the final point of the certification journey. With CCNP Enterprise, the individual becomes eligible for higher-level CCIE Enterprise Wireless and CCIE Enterprise Infrastructure certificates.

NO.43 Campus users report a poor wireless experience. An engineer investigating the issue notices that in high-density areas, the wireless clients fail to switch the AP to which are automatically connected. This sticky client behavior is causing roaming issues. Which feature must the engineer configure?

Load balancing and band select

optimized roaming

Layer 3 roaming

Layer 2 roaming

Explanation
https://www.cisco.com/c/en/us/td/docs/wireless/controller/technotes/80/hdx_final/b_hdx_dg_final/high_den

NO.44 A wireless engineer is hired to design a network for a technology company. The company campus has four buildings and a warehouse with access points that provide full wireless coverage as well as a pair of WLCs located in the core of the network. Which type of wireless architecture is being used?

unified deployment

autonomous deployment

centralized deployment

distributed deployment

NO.45 Guest anchoring is configured for a newly created SSID for your company. It has been noticed that the mobility tunnels are not up, and that MPING fails from your foreign WLC to the anchor WLC. What is the reason that it is failing?

A rule is needed at the firewall to allow UDP port 16666 for communication to work.

A rule is needed at the firewall to allow UDP port 97 for communication to work.

A rule is needed at the firewall to allow TCP port 97 for communication to work.

A rule is needed at the firewall to allow TCP port 16666 for communication to work.

NO.46 An engineer has successfully configured high availability and SSO using two Cisco 5508 Wireless LAN Controllers. The engineer can access the Active Primary WLC, but the Secondary Standby WLC is not accessible. Which two methods allow access to the standby unit? (Choose two.)

via the console connection

SSH to the redundancy management interface of the primary WLC

SSH to the service port interface

SSH to the virtual interface of the secondary WLC

SSH to the management interface of the primary WLC

NO.47 An engineer must ensure that the wireless network can accomplish fast secure roaming by way of caching keys on the access points. Which key caching mechanism is enabled by default on a Cisco AireOS WLC?

SKC

OKC

802.11r

CCKM

NO.48 Which of the following statements best describes the purpose of ARP with respect to CEF?

ARP is used to build the FIB.

ARP is used to reindex the routing table.

ARP is used to build the adjacency table.

ARP is used to decrease the amount of time spent searching for an entry within a routing table.

Address Resolution Protocol (ARP) is used by Cisco Express Forwarding (CEF) to build the adjacency table.
CEF is the switching method used by Catalyst switches. Unlike traditional multilayer switching (MLS), which merely caches Layer 3 information received when traffic passes through a switch, CEF attempts to optimize the routing process by reindexing the routing table and then building an adjacency table based on the routing table information. The type of MLS performed by CEF is called topology-based switching; traditional MLS is known as route caching, demand-based switching, and flow-based switching.
The routing table is reindexed by using a binary search method. The reindexed routing table is called the forwarding information base (FIB). Reindexing the routing table reduces the amount of time spent searching for an entry within a routing table.
After the FIB is created, an adjacency table is created to map the appropriate Layer 2 next-hop address or addresses to each FIB entry. ARP is used to retrieve the Layer 2 address information. If multiple Layer 2 next- hop addresses are available for an entry in the FIB, then CEF can employ load balancing for packets headed to that destination.
The final result is a single database of routing information (FIB) is built for the switching hardware.
Two extremely useful commands for verifying CEF are:
show ip cef network address – displays entries in the forwarding information base (FIB) show adjacency detail | begin adjacency address – shows information about a specific adjacency in the adjacency table Both commands are shown below with explanations.
SwitchA# show ip cef 192.168.6.0
192.168.6.0/24, version 302, cached adjacency 192.168.166.5, 0 packets, 0 bytes Via 192.168.166.5, VLAN 185, 0 dependencies Next-hop 192.168.166.5, VLAN 185 Valid cached adjacency Above it can be determined that there is a valid CEF entry for the destination network 192.168.6.0 and that there is a valid cached adjacency to the 192.168.166.5 next hop IP address.
In the command output below, it can be determined that 005565946856 is the MAC address of the
192.168.166.5 next-hop address:
SwitchA# show adjacency detail | begin 192.168.166.5
IP VLAN 185 192.168.166.5(6) 0 packets, 0 bytes
005565946856
Objective:
Layer 2 Technologies
Sub-Objective:
Configure and verify switch administration
References:
Cisco > Cisco IOS IP Switching Configuration Guide, Release 12.4 > Part 1: Cisco Express Forwarding > Cisco Express Forwarding Overview > Cisco Express Forwarding Adjacency Tables Overview Cisco > Cisco IOS IP Switching Command Reference > show adjacency through show ipv6 cef with source > show adjacency Cisco > Cisco IOS IP Switching Command Reference > show adjacency through show ipv6 cef with source > show ip cef

NO.49 A wireless engineer is performing a post verification of a wireless network. Which two metrics does the engineer verify to ensure that the wireless network can support voice services? (Choose two.)

The coverage area must have a noise floor that does not exceed -87 dBm.

The client device must have at least an -67 dBm RSSI.

The rate of retransmitted packets must be 15 percent or below.

The rate of retransmitted packets must be 20 percent or below.

The client device must have at least an -65 dBm RSSI.

NO.50 A wireless engineer is performing a post verification of a wireless network. Which two metrics does the engineer verify to ensure that the wireless network can support voice services? (Choose two.)

The coverage area must have a noise floor that does not exceed -87 dBm.

The client device must have at least an -67 dBm RSSI.

The rate of retransmitted packets must be 15 percent or below.

The rate of retransmitted packets must be 20 percent or below.

The client device must have at least an -65 dBm RSSI.

NO.51 Multiple WLCs are implemented in a high-availability configuration in a mobility group. APs are deployed with only a primary controller assigned. By default, which mobility group member controller do the orphaned APs join in the event of a failed controller?

controller with the most available AP free license capacity

controller with the lowest percent of associated APs per license capacity

controller with the least CPU utilization over the last reporting period

controller with the least number of associated APs

Section: Mobility

NO.52 A high-density wireless network is designed. Which Cisco WLC configuration setting must be incorporated in the design to encourage clients to use the 5 GHz spectrum?

Band Select

RRM

Cisco Centralized Key Management

load balancing

NO.53 Prior to enabling PPPoE in a virtual private dialup network group, which task must be completed?

Disable CDP on the interface.

Execute the vpdn enable command.

Execute the no switchport command.

Enable QoS FIFO for PPPoE support.

Enabling PPPoE in a VPDN Group
Perform this task to enable PPPoE in a virtual private dial-up network (VPDN) group.
Restrictions
This task applies only to releases prior to Cisco IOS Release 12.2(13)T.
SUMMARY STEPS
1. enable
2. configure terminal
3. vpdn enable
4. vpdn-group name
5. request-dialin
6. protocol pppoe
DETAILED STEPS

Reference: http://www.cisco.com/en/US/docs/ios/12_2t/12_2t2/feature/guide/ ftpppoec_support_TSD_Island_of_Content_Chapter.html

NO.54 A high-density wireless network is designed. Which Cisco WLC configuration setting must be incorporated in the design to encourage clients to use the 5 GHz spectrum?

Band Select

RRM

Cisco Centralized Key Management

load balancing

NO.55 A customer has restricted the AP and antenna combinations for a design to be limited to one model integrated antenna AP for carpeted spaces and one model external antenna AP with high gam antennas tor industrial, maintenance, or storage areas When moving between a carpeted area to an industrial area, the engineer forgets to change survey devices and surveys several APs Which strategy will reduce the negative impact of the design?

Resurvey and adjust the design

Deploy unsurveyed access points to the design

Deploy the specified access points per area type

increase the Tx power on incorrectly surveyed access points

NO.56 Multiple WLCs are implemented in a high-availability configuration in a mobility group. APs are deployed with only a primary controller assigned. By default, which mobility group member controller do the orphaned APs join in the event of a failed controller?

controller with the most available AP free license capacity

controller with the lowest percent of associated APs per license capacity

controller with the least CPU utilization over the last reporting period

controller with the least number of associated APs

https://mrncciew.com/2013/04/07/ap-failover/

NO.57 Which statement about AP failover priority for access points when configured with priority 1 or 4 is true?

When configured with priority 1, the access point is assigned with the highest priority level and it is marked as critical. This access point fails over before other access points with the lower priority when there is primary controller failure.

When configured with priority 4, the access point is assigned with the highest priority level and it is marked as critical. This access point fails over before other access points with the lower priority when there is primary controller failure.

When configured with priority 4, the access point is assigned with the lowest priority level and it is marked as low. This access point fails over after other access points with the higher priority when there is primary controller failure.

When configured with priority 1, the access point is assigned with the medium priority level and it is marked as medium. This access point fails over after other access points with the higher priority when there is primary controller failure.
